DIMENSIONS |
Overall length: |
|
4714 mm (185.6 in), including winch and bull bar |
| Overall width: |
2189 mm (86.2 in) |
| Height: |
2205 mm (86.8 in), including roof rack and jerry cans |
| Wheelbase: |
2540 mm (100.0 in) |
| Track, front & rear: |
1486 mm (58.5 in) |
| Ground clearance: |
205 mm (8.1 in) (unladen) |
| Curb weight: |
2065 kg (4552 Ibs) (without accessories) |
| Fuel tank capacity: |
88.6 litres (23.4 gallon) |
| |
|
ENGINE |
|
| Intercooled, turbocharged direct-injection diesel engine with four cylinders in-line |
| Cubic Capacity: |
2495 cc (152 cu in) |
| Bore: |
90.47 mm (3.56 in) |
| Stroke: |
97 mm (3.82 in) |
| Compression ratio: |
19.5:1 |
| Max. power(DIN net): |
83 kW (111.3 bhp) at 4,000 rpm |
| Max. torque: |
265 Nm (195 lb ft) at 1,800 rpm |
| |
|
TRANSMISSION |
|
| Type: |
Four-wheel drive |
| Gearbox: |
10 forward, 2 reverse gears |
| Transfer ratios: |
High 1.214:1/Low 3.308:1 |
| Final drive ratio: |
3.54:1 |
| Clutch: |
Single 267 mm diameter, hydraulically operated dry plate |
| |
| SUSPENSION |
| Front: |
Live beam axle located by radius arm, panhard rod, telescopic hydraulic dampers, single-rate coil springs |
| Rear: |
Live beam axle located by trailing links, 'A' frame, telescopic hydraulic dampers, heavy duty single rate coil springs with additional helper springs |
| |
| STEERING |
|
| Type: |
Worm and roller. Power assisted with a minimum turning radius of 5.95 m (3.75 turns from lock to lock) |
| |
|
BRAKES |
|
| Front: |
298 (11.7 in) mm dia. vent discs, servo assisted |
| Rear: |
290 (11.4 in) mm dia. plain discs, servo assisted |
| |
WHEELS
5.5" x 16" |
|
| |
| |
TIRES
7.00" x 16" Michelin XCL radials |
|
